Name: Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke
Brand: FLY AUTOMATION
SKU: P1F-S032MC-0025-0000 P1F-S040MC-0025-0000 P1F-S050MC-0025-0000 P1F-S063MC-0025-0000 P1F-S032MC-0040-
Price: 90.00 USD
Availability: InStock

Rumah Produk Pneumatik udara silinder

Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke

Detail produk:

Tempat asal:	CINA JEPANG
Nama merek:	Parker or OEM
Nomor model:	P1F-S032MC-0025-0000 P1F-S040MC-0025-0000 P1F-S050MC-0025-0000 P1F-S063MC-0025-0000 P1F-S032MC-0040-

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 pc
Harga:	EXW USD15-165
Kemasan rincian:	kantong plastik, karton, tas opp
Waktu pengiriman:	8-10 hari kerja
Syarat-syarat pembayaran:	T/T, Western Union, Paypal
Menyediakan kemampuan:	1200 pcs per bulan

Kontak

Detil Deskripsi produk

Barrel silinder:	Paduan aluminium tempa anodized	Desain:	Batang Piston Piston
Tekanan kerja:	0-10bar	Media operasi:	Udara terkompresi ke ISO 8573-1: 2010 [7: 4: 4]
Catatan tentang Operasi dan Media Pilot:	Operasi yang dilumasi mungkin (dalam hal ini operasi yang dilumasi akan selalu diperlukan)	Suhu sekitar:	-20 ° C-80 ° C.
Bahan piston:	Baja paduan tinggi	Segel:	Poliuretan, karet nitril dan karet fluoro
Bantalan dan penutup akhir:	Aluminium aloy yang tempa	Konstruksi:	ISO 15552 Standar, VDMA 24364-B1/B2-L (Kompatibilitas Cleanroom), ROHS-Compliant
Menyoroti:	Parker ISO15552 pneumatic cylinder , double acting air cylinder 32-125mm , P1F pneumatic cylinder with warranty

Parker ISO15552 P1F Double acting pneumatic cylinder 32-125mm Bore 5-2000mm stroke -20°C to +80°C P1F-S032MC-0070-0000 P1F-S040MC-0080-0000 P1F-S050MC-0125-0000 P1F-S063MC-0150-0000

Order Codes:

P1F-S032MC-0025-0000	P1F-S040MC-0025-0000	P1F-S050MC-0025-0000	P1F-S063MC-0025-0000
P1F-S032MC-0040-0000	P1F-S040MC-0040-0000	P1F-S050MC-0040-0000	P1F-S063MC-0040-0000
P1F-S032MC-0050-0000	P1F-S040MC-0050-0000	P1F-S050MC-0050-0000	P1F-S063MC-0050-0000
P1F-S032MC-0060-0000	P1F-S040MC-0060-0000	P1F-S050MC-0060-0000	P1F-S063MC-0060-0000
P1F-S032MC-0070-0000	P1F-S040MC-0070-0000	P1F-S050MC-0070-0000	P1F-S063MC-0070-0000
P1F-S032MC-0075-0000	P1F-S040MC-0075-0000	P1F-S050MC-0075-0000	P1F-S063MC-0075-0000
P1F-S032MC-0080-0000	P1F-S040MC-0080-0000	P1F-S050MC-0080-0000	P1F-S063MC-0080-0000
P1F-S032MC-0100-0000	P1F-S040MC-0100-0000	P1F-S050MC-0100-0000	P1F-S063MC-0100-0000
P1F-S032MC-0125-0000	P1F-S040MC-0125-0000	P1F-S050MC-0125-0000	P1F-S063MC-0125-0000
P1F-S032MC-0130-0000	P1F-S040MC-0130-0000	P1F-S050MC-0130-0000	P1F-S063MC-0130-0000
P1F-S032MC-0135-0000	P1F-S040MC-0135-0000	P1F-S050MC-0135-0000	P1F-S063MC-0135-0000
P1F-S032MC-0140-0000	P1F-S040MC-0140-0000	P1F-S050MC-0140-0000	P1F-S063MC-0140-0000
P1F-S032MC-0150-0000	P1F-S040MC-0150-0000	P1F-S050MC-0150-0000	P1F-S063MC-0150-0000
P1F-S032MC-0160-0000	P1F-S040MC-0160-0000	P1F-S050MC-0160-0000	P1F-S063MC-0160-0000
P1F-S032MC-0200-0000	P1F-S040MC-0200-0000	P1F-S050MC-0200-0000	P1F-S063MC-0200-0000
P1F-S032MC-0250-0000	P1F-S040MC-0250-0000	P1F-S050MC-0250-0000	P1F-S063MC-0250-0000
P1F-S032MC-0320-0000	P1F-S040MC-0320-0000	P1F-S050MC-0320-0000	P1F-S063MC-0320-0000
P1F-S032MC-0400-0000	P1F-S040MC-0400-0000	P1F-S050MC-0400-0000	P1F-S063MC-0400-0000
P1F-S032MC-0500-0000	P1F-S040MC-0500-0000	P1F-S050MC-0500-0000	P1F-S063MC-0500-0000
P1F-S032MC-0600-0000	P1F-S040MC-0600-0000	P1F-S050MC-0600-0000	P1F-S063MC-0600-0000
P1F-S032MC-0700-0000	P1F-S040MC-0700-0000	P1F-S050MC-0700-0000	P1F-S063MC-0700-0000
P1F-S032MC-0750-0000	P1F-S040MC-0750-0000	P1F-S050MC-0750-0000	P1F-S063MC-0750-0000
P1F-S032MC-0800-0000	P1F-S040MC-0800-0000	P1F-S050MC-0800-0000	P1F-S063MC-0800-0000
P1F-S032MC-0900-0000	P1F-S040MC-0900-0000	P1F-S050MC-0900-0000	P1F-S063MC-0900-0000
P1F-S032MC-1000-0000	P1F-S040MC-1000-0000	P1F-S050MC-1000-0000	P1F-S063MC-1000-0000
P1F-S032MC-1100-0000	P1F-S040MC-1100-0000	P1F-S050MC-1100-0000	P1F-S063MC-1100-0000
P1F-S032MC-1200-0000	P1F-S040MC-1200-0000	P1F-S050MC-1200-0000	P1F-S063MC-1200-0000
P1F-S032MC-1300-0000	P1F-S040MC-1300-0000	P1F-S050MC-1300-0000	P1F-S063MC-1300-0000
P1F-S032MC-1400-0000	P1F-S040MC-1400-0000	P1F-S050MC-1400-0000	P1F-S063MC-1400-0000
P1F-S032MC-1500-0000	P1F-S040MC-1500-0000	P1F-S050MC-1500-0000	P1F-S063MC-1500-0000
P1F-S032MC-1600-0000	P1F-S040MC-1600-0000	P1F-S050MC-1600-0000	P1F-S063MC-1600-0000
P1F-S032MC-1700-0000	P1F-S040MC-1700-0000	P1F-S050MC-1700-0000	P1F-S063MC-1700-0000
P1F-S032MC-1800-0000	P1F-S040MC-1800-0000	P1F-S050MC-1800-0000	P1F-S063MC-1800-0000
P1F-S032MC-1900-0000	P1F-S040MC-1900-0000	P1F-S050MC-1900-0000	P1F-S063MC-1900-0000
P1F-S032MC-2000-0000	P1F-S040MC-2000-0000	P1F-S050MC-2000-0000	P1F-S063MC-2000-0000
P1F-S080MC-0025-0000	P1F-S100MC-0025-0000	P1F-S125MC-0025-0000
P1F-S080MC-0040-0000	P1F-S100MC-0040-0000	P1F-S125MC-0040-0000
P1F-S080MC-0050-0000	P1F-S100MC-0050-0000	P1F-S125MC-0050-0000
P1F-S080MC-0060-0000	P1F-S100MC-0060-0000	P1F-S125MC-0060-0000
P1F-S080MC-0070-0000	P1F-S100MC-0070-0000	P1F-S125MC-0070-0000
P1F-S080MC-0075-0000	P1F-S100MC-0075-0000	P1F-S125MC-0075-0000
P1F-S080MC-0080-0000	P1F-S100MC-0080-0000	P1F-S125MC-0080-0000
P1F-S080MC-0100-0000	P1F-S100MC-0100-0000	P1F-S125MC-0100-0000
P1F-S080MC-0125-0000	P1F-S100MC-0125-0000	P1F-S125MC-0125-0000
P1F-S080MC-0130-0000	P1F-S100MC-0130-0000	P1F-S125MC-0130-0000
P1F-S080MC-0135-0000	P1F-S100MC-0135-0000	P1F-S125MC-0135-0000
P1F-S080MC-0140-0000	P1F-S100MC-0140-0000	P1F-S125MC-0140-0000
P1F-S080MC-0150-0000	P1F-S100MC-0150-0000	P1F-S125MC-0150-0000
P1F-S080MC-0160-0000	P1F-S100MC-0160-0000	P1F-S125MC-0160-0000
P1F-S080MC-0200-0000	P1F-S100MC-0200-0000	P1F-S125MC-0200-0000
P1F-S080MC-0250-0000	P1F-S100MC-0250-0000	P1F-S125MC-0250-0000
P1F-S080MC-0320-0000	P1F-S100MC-0320-0000	P1F-S125MC-0320-0000
P1F-S080MC-0400-0000	P1F-S100MC-0400-0000	P1F-S125MC-0400-0000
P1F-S080MC-0500-0000	P1F-S100MC-0500-0000	P1F-S125MC-0500-0000
P1F-S080MC-0600-0000	P1F-S100MC-0600-0000	P1F-S125MC-0600-0000
P1F-S080MC-0700-0000	P1F-S100MC-0700-0000	P1F-S125MC-0700-0000
P1F-S080MC-0750-0000	P1F-S100MC-0750-0000	P1F-S125MC-0750-0000
P1F-S080MC-0800-0000	P1F-S100MC-0800-0000	P1F-S125MC-0800-0000
P1F-S080MC-0900-0000	P1F-S100MC-0900-0000	P1F-S125MC-0900-0000
P1F-S080MC-1000-0000	P1F-S100MC-1000-0000	P1F-S125MC-1000-0000
P1F-S080MC-1100-0000	P1F-S100MC-1100-0000	P1F-S125MC-1100-0000
P1F-S080MC-1200-0000	P1F-S100MC-1200-0000	P1F-S125MC-1200-0000
P1F-S080MC-1300-0000	P1F-S100MC-1300-0000	P1F-S125MC-1300-0000
P1F-S080MC-1400-0000	P1F-S100MC-1400-0000	P1F-S125MC-1400-0000
P1F-S080MC-1500-0000	P1F-S100MC-1500-0000	P1F-S125MC-1500-0000
P1F-S080MC-1600-0000	P1F-S100MC-1600-0000	P1F-S125MC-1600-0000
P1F-S080MC-1700-0000	P1F-S100MC-1700-0000	P1F-S125MC-1700-0000
P1F-S080MC-1800-0000	P1F-S100MC-1800-0000	P1F-S125MC-1800-0000
P1F-S080MC-1900-0000	P1F-S100MC-1900-0000	P1F-S125MC-1900-0000
P1F-S080MC-2000-0000	P1F-S100MC-2000-0000	P1F-S125MC-2000-0000

HOW TO ORDER:

Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke

Datasheet:

Product type Standard cylinder according to ISO 15552
Bore size 32 - 125 mm
Stroke length 5 - 2000 mm
Versions Double acting
Cushioning Adjustable air cushioning
Position sensing Proximity sensor
Installation ISO cylinder and piston rod mountings

Parker ISO15552 P1F Pneumatic Cylinder 32-125mm Bore 5-2000mm Stroke
