Liandong-U-Gu 17-2#, Jalan Shengyuan 1#, Jalan Jiangkou, Distrik Fenghua, Kota Ningbo, Provinsi Zhejiang, Cina | airwolf@flyautomatic.com |
Tempat asal: | Cina |
Nama merek: | FESTO |
Nomor model: | DGC-12-600 - IPK |
Kuantitas min Order: | 1 pc |
---|---|
Harga: | EXW USD300-400 |
Kemasan rincian: | kantong plastik, karton |
Waktu pengiriman: | 7-10 hari kerja |
Syarat-syarat pembayaran: | T/T, Serikat Barat, Paypal |
Menyediakan kemampuan: | 20 pcs per bulan |
Jenis: | DGC-12-600 - IPK | Bagian No: | 530907 |
---|---|---|---|
Merek: | FESTO | Diameter piston: | 12 mm |
Posisi Pemasangan: | Opsional | Segel bahan: | POM TPE-U(PU) |
Cahaya Tinggi: | Linear Drive Double Acting Pneumatic Cylinder,530907 Pneumatic Air Cylinders,12mm Piston Pneumatic Air Cylinders |
About product
Basic design, plain or ball bearing guide, guide axis without actuator
All settings accessible from one side
Available with variable end stops and intermediate position module
Compact – installation length relative to stroke
Loads and devices can be directly mounted on the slide
Long strokes with no restrictions
Virtually no leakage
Technical Data
Piston diameter | 12 mm |
Mounting position | optional |
Guide | Basic guide Recirculating ball bearing guide |
Position detection | Via proximity switch |
Operating pressure | 0.25 MPa ... 0.8 MPa |
Operating pressure | 2.5 bar ... 8 bar |
Mode of operation | Double-acting |
Corrosion resistance class CRC | 1 - Low corrosion stress 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Type of mounting | With accessories |
Note on materials | RoHS-compliant |
Material cover | Wrought aluminium alloy |
Material seals | POM TPE-U(PU) |
Package picture
A wide range of products with excellent prices. Please hurry to me!
